Cr:YAG
當前位置：
首頁 ? Products ? 被動調Q晶體 ? Cr:YAG
我司的Cr4+：YAG晶體，又稱摻鉻釔鋁石榴石晶體，化學式為Cr:Y3Al5O12，是一種綜合性比較優良的調Q晶體產品。不僅可以用作Q 開關，還可以用作增益介質，因?yàn)樗哂袃?yōu)異的物理化學性質。在激光測距儀、LIDAR和LIBS 系統的無源Q開關激光器領域有廣泛的應用。Cr:YAG具有化學穩定、耐用、抗紫外線、導熱性好、損傷閾值高（>500 MW/cm2）、操作簡單等優點，正在超越LiF和有機染料等傳統材料。Cr:YAG是用于無源Q開關（激光二極管或燈泵浦）Nd:YAG、Nd:YLF、Nd:YVO4的優秀且廣泛使用的電光材料和其他 0.8~1.2μm 的 Nd（或Yb）摻雜激光器，也是一種可用作CW、脈沖或自鎖?？烧{(diào)諧 NIR 固態激光器的活性介質，可調諧范圍為1340 – 1580nm以及工作波長為950-1100nm的激光器中用于Q開關的介質。1060 nm 波段的吸收飽和可用于具有閃光燈或激光二極管泵浦的小型 Nd:YAG 振蕩器，而不是基于染料或LiF:F中心無源Q開關，使Cr4+:YAG晶體可以實現自鎖模 (KML) 狀態。它提供了在1450-1580nm處構建脈沖持續時間短于100fs的激光源的機會。
特點
- 高導熱率
- 高損傷閾值（> 500MW/cm2）
- 優異的理化特性
- 輻射穩定性
物理和化學特性
| 屬性 | 數值 |
| 化學式 | Cr4+:Y3Al5O12 |
| 晶體結構 | cubic – la3d |
| 晶格參數? | 12.01 |
| 取向 | [100] or [110] < ±0.5° |
| 質量密度 | 4.56 g/cm3 |
| 莫氏硬度 | 8.5 |
| 楊氏模量 | 335 GPa |
| 抗拉強度 | 2 GPa |
| 熔點 | 1970°C |
| 導熱系數 | 0.1213 |
| 比熱/（J·g-1·K-1） | 0.59 |
| 熱膨脹/（10-6 /°C @ 25°C） | 7.8 <111> |
| 7.7 <110> | |
| 8.2 <100> | |
| 抗熱震參數 | 800 W/m |
| 消光比 | 25dB |
| 泊松比 | 0.25 |
| 折射率@ 1064 nm | 1.83 |
| 電荷補償離子 | Ca2+, Mg2+ |
光學性質
| 屬性 | 數值 |
| 光密度 | 0.1 to 0.8 |
| 熒光壽命 | 3.4μs |
| 濃度 | 0.5 mol % ~ 3 mol % |
| 發射波長 | 1350 nm ~ 1600 nm |
| 吸收系數 | 1.0 cm-1?～ 7 cm-1 |
| 基態吸收截面 | 4.3×10-18?cm2 |
| 發射態吸收截面 | 8.2×10-19?cm2 |
| 傳輸 | 10% to 90% |
| 涂層 | AR≤ 0.2% @1064nm |
| 損傷閾值 | > 500 MW / cm2 |
拋光
| 屬性 | 數值 |
| 方向公差 | < 0.5° |
| 厚度/直徑公差 | ±0.05 mm |
| 表面平整度 | <λ/8@632 nm |
| 波前失真 | <λ/4@632 nm |
| 表面質量 | 5-Oct |
| 平行 | 10〞 |
| 垂直 | 5ˊ |
| 通光孔徑 | >90% |
| 倒角 | <0.1×45° |
| HR涂層 | <= 0.2% (@ 1340nm) |
| 最大尺寸 | 2*2-15*15 mm×20mm |
光譜
Q晶體-發射譜-南京光寶-CRYLINK-300x211-1.jpg) | Q晶體-吸收譜-南京光寶-CRYLINK-300x211-1.jpg) |
Q晶體-其它譜2-南京光寶-CRYLINK-300x211-1.jpg) | Q晶體-其它譜1-南京光寶-CRYLINK-300x211-1.jpg) |
參考文獻
| [1]? Saiki T ,? Nakatsuka M ,? Fujioka K , et al. Cross-relaxation and spectral broadening of gain for Nd/Cr:YAG ceramic lasers with white-light pump source under high-temperature operation[J]. Optics Communications, 2011, 284(12):2980-2984. |
|---|
| [2]? Saiki T ,? Funahashi K ,? Motokoshi S , et al. Temperature characteristics of small signal gain for Nd/Cr:YAG ceramic lasers[J]. Optics Communications, 2009, 282(4):614-616. |
| [3]? Wu Y ,? Jiang L ,? Qiu F , et al. Fabrication of transparent Yb,Cr:YAG ceramics by a solid-state reaction method[J]. Ceramics International, 2006, 32(7):785-788. |
| [4] Jiying, Peng, Yi, et al. Passively Q-switched mode locking in a compact Nd:GdVO4/Cr:YAG self-Raman laser[J]. Optics Communications, 2012, 285(24):5334-5336. |
| [5]? Peng J Y ,? Zheng Y ,? Shi Y X , et al. Passively Q-switched a -cut Nd:GdVO 4 self-Raman laser with Cr:YAG[J]. Optics & Laser Technology, 2012, 44( 7):2175-2177. |
| [6] A low viscosity slurry system for fabricating chromium doped yttrium aluminum garnet (Cr:YAG) transparent ceramics[J]. Journal of the European Ceramic Society, 2015, 35(14):S095522191530025X. |
| [7]? Yi X ,? Zhou S ,? Chen C , et al. Fabrication of Ce:YAG, Ce,Cr:YAG and Ce:YAG/Ce,Cr:YAG dual-layered composite phosphor ceramics for the application of white LEDs[J]. Ceramics International, 2014, 40(5):7043-7047. |
| [8]? Honda Y ,? Motokoshi S ,? Jitsuno T , et al. Temperature dependence of optical properties in Nd/Cr:YAG materials[J]. Journal of Luminescence, 2014, 148:342-346. |
| [9] Lin, Hong-Yi, Sun, et al. Comparative study between Nd:GYSGG and Nd:YAG lasers passively Q-switched by a Cr:YAG crystal[J]. Journal for Light and Electronoptic, 2018. |
| [10]? Villafana-Rauda E , R Chiu,? Mora-Gonzalez M , et al. Dynamics of a Q-switched Nd:YVO4/Cr:YAG laser under periodic modulation[J]. Results in Physics, 2018, 12. |
| [11]? Chen X ,? Lu T ,? Wei N , et al. Fabrication and photoluminescence properties of Cr:YAG and Yb,Cr:YAG transparent ceramic[J]. Optical Materials, 2015, 49:330-336. |
| [12]? Cafiso S ,? Ugolotti E ,? Schmidt A , et al. Sub-100-fs mode-locking of the Cr:YAG laser using monolayer graphene saturable absorber[C]// Cleo. IEEE, 2013. |
| [13]? Bernard J E ,? Alcock A J ,? Chepurov S V , et al. Measurement of the frequency of acetylene transitions at 1540 nm with a mode-locked Cr:YAG laser[C]// Leos Summer Topical Meetings. IEEE, 2005. |
| [14]? Chen J C ,? Lo C Y ,? Huang K Y , et al. Mapping of Cr ions and refraction index profile in Cr:YAG crystal fiber with double-cladding structure[J]. Annals of Physical and Rehabilitation Medicine, 2004. |
| [15]? Jaspan M A ,? Welford D ,? Xiao G , et al. Atypical behavior of Cr:YAG passively Q-switched Nd:YVO4 microlasers at high-pumping rates[J]. Filtration Industry Analyst, 2000. |
| [16]? Lin J H , MD Wei,? Hsu H H , et al. High peak power output of a diode-pumped Q-switched and mode locked Nd:LuVO4 with Cr:YAG saturable absorber[C]// Conference on Lasers & Electro-optics-pacific Rim. IEEE, 2007. |
| [17]? Dong J ,? Shirakawa A ,? Ueda K I , et al. Composite Yb:YAG/Cr:YAG ceramics self-Q-switched laser[C]// Conference on Lasers & Electro-optics. IEEE, 2008. |
| [18]? Sorokin E ,? Naumov S ,? Kalashnikov V L , et al. Spectral broadening of 50 fs Cr:YAG pulses around 1.5 /spl mu/m in the tapered fiber.? 2003. |
| [19] D Welford,? Jaspan M A . Single-frequency operation of a Cr:YAG laser from 1332 to 1554 nm[J]. Journal of the Optical Society of America B, 2004, 21(12):2137-2141. |
| [20]? Saiki T ,? Imasaki K ,? Motokoshi S , et al. Oscillation Property of Disk-Type Nd/Cr:YAG Ceramic Lasers with Quasi-Solar Pumping[C]// Conference on Lasers & Electro-optics. American Institute of Physics, 2006. |
| [21]? Lo C Y ,? Tu S Y ,? Huang K Y , et al. Fused-silica-clad Cr:YAG fiber. IEEE, 2003. |
| [22] Tsunekane, Taira. High temperature operation of passively Q-switched, Cr:YAG/Nd:YAG micro-laser for ignition of engines. IEEE, 2009. |
| [23]? Cho W B ,? Schmidt A ,? Sun Y C , et al. Carbon-Nanotube Mode-Locked Cr:YAG Laser[C]// Lasers & Electro-optics. IEEE, 2010. |
如果你對我們的Cr:YAG感興趣，請聯系我們獲取價格或申請樣品。
